Description
The VoltX 24V 100Ah Premium LiFePO4 Battery will get your attention in one glance with its clear-case design. This means you can easily see the high-grade materials inside your battery & ensure the best quality. Get double the amount of energy compared to traditional lead-acid batteries and up to 4000 lifecycles for long-lasting use. This battery pack houses a built-in battery management system (BMS) just like all our LiFePO4 batteries to provide automatic protection against overcharging, undercharging, overheating, and short circuits. The final touches include a convenient power voltage display to help you quickly monitor your battery’s metrics.
Features
Clear-case design
Prismatic cells
Power voltage display
Built-in battery management system (BMS)
Protects against overcharging, undercharging, overheating, and short circuits
Up to 4000 lifecycles
Safe & stable battery technology
High energy density
Portable at 19.5kgs
5-years Australian warranty
SPECIFICATIONS
Nominal Voltage: 25.6V
Nominal Capacity: 100Ah
Charging Voltage: 27.2?27.6V
Rated Energy: 2.56KWh
Max. Charging Current: 50A
Life Cycle (@25°C, 0.5C/0.25C, 80%DOD): 4000 Cycles
Max. Discharging Current: 100A
Discharge Cut-off Voltage: 22.4V
Internal Resistance Fully Charged@ 25°C: ≤8mΩ
Thermal Management: Nature cooling
Cell: 3.2V-100Ah
Cells Grouping: 8S1P
Series Connection: Yes, max 3 batteries
Parallel Connection: Yes, max 6 batteries
PACKAGE CONTENTS
1 x Lithium Battery
1 x User Manual
